HOT ! 新発売の 20A SOGTICPS : Amazon.com MPPT 12V Controller Charger Solar PowerGenerationEquipment

• Wide load operating mode makes it easier to apply product to a variety of loads
• The advanced load-starting system allows for smooth operation of large loads
• The user-friendly design and dynamic interface of the browser ensures convenient and intuitive operation
• This product provides over-charge, over-discharge, overload protection and short circuit protection
• Applying the battery regularly or during over-discharge can effectively prevent battery imevenness and sulfation and prolong battery life

Features
1.12V/24V system voltage is automatically recognized.
2. Upgraded 3-Stage PWM charging algorithm.
3. Adopts temperature compensation, the charging parameters can be adjusted automatically.
Rated Current
10A
20A
20A
Current display function.
No.
No.
Yes
System Voltage
Automatic recognition of 12V/24V
No load loss
<; 10mA/12V 12mA/24V
Max. Solar energy input voltage
<;55V
Max. Battery end voltage
<;35V
Over Voltage Protection
17.0V x 2/24V
Equalizes charging voltage
14.6V x 2/24V
Boost Charging Voltage
14.4V x 2/24V
Floating Charging Voltage
13.8V x 2/24V
Charging Recovery Voltage
13.2V x 2/24V
Over discharge recovery voltage
12.6V x 2/24V
Over discharge voltage
11.1V x 2/24V
Equalization between charges
30 days
Equalizes charging time
1H
Reduces charging time
2nd Hour
Temperature compensation
-3.0mV//2V
Dimmer Voltage
Dimmable at 5V, x2/24V
Dimmer Off 6V, x 2/24V
Dimming Time
1 min.
Operating Temp.
-25 to +55
